CC Synaxis Connector

CC Synaxis Connector is a NeoForge compatibility mod for connecting CC: Tweaked computers with Synaxis Cimulink plant ports.

It adds bridge-style circuit boards that let Lua programs, Synaxis circuits, and CSV logging workflows exchange values without requiring custom scripts on both sides of every connection.

Highlights

• Connect CC: Tweaked peripherals and Synaxis Cimulink ports.
• Expose named one-way real/boolean bridge signals.
• Use a Super Hub board to wrap adjacent CC peripherals and Synaxis plant values.
• Read selected Synaxis values from CC Lua through a single peripheral.
• Write CC getter/setter-style peripheral methods into Synaxis ports.
• Record Synaxis signals to CSV files with an in-game table editor.
• Supports both English and Simplified Chinese UI text.

Requirements

This mod is not standalone. Install it together with CC: Tweaked, Synaxis, and the dependencies required by Synaxis.

Tested target:

• Minecraft 1.21.1
• NeoForge 21.1.226+
• CC: Tweaked 1.118.0+
• Synaxis 1.3.4+
• Sable 1.1.3+
• Sable Schematic API 0.2.6+
• LDLib2 2.2.17+
• Create 6.0.10+
• Flywheel 1.0.6+

The generated jar does not include CC: Tweaked, Synaxis, Sable, Create, or their assets. You must obtain those mods from their official distribution channels.

Blocks

CC: Synaxis Bridge

The Bridge is a small Cimulink-style board for manually created one-way signal channels.

Each bridge channel has:

• a unique name, such as bridge_1
• a type: real or boolean
• a direction: cc_to_synaxis or synaxis_to_cc
• an optional "save last value" setting for missing Synaxis input

Use the block UI to create and remove bridge channels. Use Synaxis wiring tools to connect the generated ports. CC computers can access the block as a peripheral named cc_synaxis_bridge.

CC: Synaxis Super Hub

The Super Hub is a board for wrapping nearby devices into ports for the other side of the bridge.

It has two UI pages:

• Providing to Synaxis: select wrapped CC or Synaxis capabilities and expose them as Synaxis Cimulink ports.
• Providing to CC: select wrapped CC or Synaxis capabilities and expose them through the Super Hub CC peripheral.

For CC peripherals, getter-like methods such as getSpeed(), isRunning(), or hasFuel() are treated as readable values. Setter-like methods such as setSpeed(value) become writable inputs where possible.

For Synaxis, the hub reads available plant values through Synaxis bus/plant-port style access and presents compatible values to CC or to Synaxis ports.

Log Output Assistant

The Log Output Assistant is a Synaxis input board that writes signal values to CSV.

It supports up to 10 columns. Each column creates one Synaxis input port and can be configured as real or boolean. Empty, never-activated inputs are written as null unless empty rows are skipped.

Main options:

• log name / output file
• row id: tick, row number, or none
• write mode: every tick, on value change, or every N ticks
• create mode: immediately, on any input, or on one selected input
• skip or write fully empty rows
• import existing CSV files from the safe output folder

CSV files are written inside the current save under:

ccsconnector_outputs/

On servers, file selection is intentionally limited to this output folder. The client import flow also only scans the client's own ccsconnector_outputs folder and uploads the selected CSV content to the server.

Basic Usage

1. Place one of the connector boards.
2. Empty-hand right-click the board to open its UI.
3. Configure the bridge, hub, or log columns you want.
4. Use Synaxis wiring tools to connect the visible ports.
5. Attach or place a CC computer next to the block when CC access is needed.
6. Use Lua peripheral calls to read or write the configured values.

CC Lua API

Bridge Peripheral

Peripheral type:

cc_synaxis_bridge

Methods:

list()
schema()
info(name)
addBridge([name], type, direction)
removeBridge(name)
get(name)
set(name, value)
lastWriteTick(name)
getSaveLastValue(name)
setSaveLastValue(name, enabled)
toggleSaveLastValue(name)

Example:

local bridge = peripheral.find("cc_synaxis_bridge")
assert(bridge, "Bridge not found")

bridge.addBridge("target_speed", "real", "cc_to_synaxis")

local value = 0
while true do
  bridge.set("target_speed", value)
  value = value + 1
  sleep(1)
end

Super Hub Peripheral

Peripheral type:

cc_synaxis_super_hub

Methods:

list()
schema()
get(name)
getAll()
refresh()
lastUpdateTick(name)

listSynaxis()
getSynaxis(name)
getAllSynaxis()
synaxisLastUpdateTick(name)

listCcCandidates()
listExposedCc()
getCc(name)
getAllCc()

expose(...)
toggleExpose(...)
set(name, value)
write(name, value)
listProvidedToSynaxis()

Exposure is configured in the Super Hub UI. Lua can read configured values and write to configured writable entries, but it does not create UI exposure rows. The expose and toggleExpose entries are reserved compatibility methods and will direct players to configure exposure in the UI.

Example:

local hub = peripheral.find("cc_synaxis_super_hub")
assert(hub, "Super Hub not found")

hub.refresh()

for name, value in pairs(hub.getAll()) do
  print(name, value)
end

Notes And Limitations

• Synaxis-facing ports currently support real and boolean values.
• Text/string values are not exposed as Synaxis ports unless Synaxis provides a compatible signal type.
• Not every CC peripheral method can be safely called without arguments. The Super Hub focuses on simple getter/setter-style methods.
• CC and Synaxis may update at different rates. Connector blocks cache values so either side can read at its own timing.
• Configure Synaxis wires with the normal Synaxis tools. Empty-hand right-click opens connector UIs.

Modpack Permission

You may include CC Synaxis Connector in modpacks, provided that all required dependencies are obtained and distributed according to their own licenses and permissions.

License

This repository is licensed under the MIT License for this project's original compatibility-layer code and assets only. See LICENSE.

CC: Tweaked, Synaxis, Sable, LDLib, Create, Flywheel, NeoForge, Minecraft, and related names, APIs, trademarks, source code, binaries, models, textures, and documentation belong to their respective owners and remain under their upstream terms.

CC Synaxis Connector is an independently created, AI-assisted compatibility mod. It is not affiliated with, endorsed by, or sponsored by the authors of CC: Tweaked, Synaxis, Sable, LDLib, Create, NeoForge, Minecraft, or Mojang/Microsoft.

See THIRD_PARTY_NOTICES.md for dependency and rights-holder notes.

Development Notes

Most dependencies are resolved from Maven by Gradle. The local libs/ directory is only for dependencies that are not currently resolved from a public Maven in this project:

• synaxis-1.3.4.jar
• sable-schematic-api-0.2.6.jar

libs/*.jar is ignored by Git, so dependency jars should not be committed.

Compatibility fallback for CC:T generic peripherals is isolated in CcTweakedInternals to keep non-public CC:T access easy to audit or remove if upstream APIs change.

Synaxis plant access goes through registered PlantEndpointProvider ports and PlantPortProviders.tryCreate.
